Description
For use in environments up to 180C. Electrical Specification: Phase Number: 2 Rated Voltage:DC 2.1V / Phase Phase Resistance: 2.1x(1±15%)Ohm Step Angle:1.8° ± 5% Rated Current: DC 1.0A / Phase Phase Inductance: 1.6x(1±20%) mH Detent Torque: 5 mN-m REF Holding Torque: 100mN-m MIN Rotate Direction: ACBDA CW HI-POT: AC600V/1mNA/1S Rotor Inertia: 16 g-cm2 REF Insulate Resistance: 100Mohm(DC500V) Insulation Class: Class H 180°C Weight: 85 g REF Identification: Serials are laser engraved Up to 180C. Motor runs significantly cooler then 17mm versions. Step Angle: 1.8 degrees Shaft Diameter: 2.5mm (integrated 10 tooth gear) Rated Current: 1A IMPORTANT: Each motor is serialized for authenticity and to prevent fraudulent returns.
